PX0686
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
Conn Power M 3 POS Screw ST Cable Mount 3 Terminal 1 Port Bulk
PDF
/
Buying Options
Total Price: USD $7.71
Unit Price: USD $7.7088
≥1 USD $7.7088
≥10 USD $6.93616
≥100 USD $6.534176
≥500 USD $6.366448
≥1000 USD $6.198896
≥3000 USD $5.528794
Inventory: 1875
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 24 Weeks
Physical
Contact Plating Nickel
Mounting Type Free Hanging (In-Line)
Shell Material POLYAMIDE
Housing Material Nylon
Technical
Packaging Bulk
Published 2001
Series PX
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
ECCN Code EAR99
Connector Type Plug, Male Blades
Number of Positions 3
Color Black
Voltage - Rated DC 250V
Option GENERAL PURPOSE
Total Number of Contacts 3
Orientation Straight
Current Rating 10A
Voltage - Rated AC 250V
Approval Agency CSA, ENEC, RCM, UL, VDE
Body Length or Diameter 1.142 inch
Operating Temperature (Max) 70°C
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.89 inch
Operating Temperature (Min) -40°C
Body Depth 2.016 inch
Contact Resistance 10mOhm
Insulation Resistance 10MOhm
Coupling Type SNAP
Connector Style IEC 320-2-2/E
Voltage - IEC 250VAC
Filter Type Unfiltered - Commercial
Accomodates a Fuse No
Dimensions
Width 29mm
Compliance
Material Flammability Rating UL94 V-0
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
