PX0598/10/63
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
AC Power Entry Modules C20 SNAP-FIT 1MM PNL 6.3MM TAB
PDF
/
Buying Options
Total Price: USD $4.87
Unit Price: USD $4.8664
≥1 USD $4.8664
≥10 USD $4.41848
≥100 USD $4.184928
≥500 USD $4.0876
≥1000 USD $3.892944
≥3000 USD $3.406339
Inventory: 123
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 24 Weeks
Physical
Contact Material Brass
Contact Plating Nickel
Mount Panel, Snap in
Mounting Type Panel Mount, Snap-In
Shell Material POLYAMIDE
Housing Material Nylon
Technical
Packaging Bulk
Published 2012
Series PX
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Quick Connect - 0.250 (6.3mm)
ECCN Code EAR99
Connector Type Receptacle, Male Blades
Number of Positions 3
Max Operating Temperature 70°C
Min Operating Temperature -40°C
Contact Finish - Mating TIN
MIL Conformance NO
DIN Conformance NO
IEC Conformance YES
Option GENERAL PURPOSE
Total Number of Contacts 3
Orientation Straight
Depth 34.5mm
Approval Agency CSA, ENEC, UL, VDE
Mating Information MULTIPLE MATING PARTS AVAILABLE
Panel Cutout Dimensions Rectangular - 32.30mm x 24.30mm
Body/Shell Style PLUG
Max Voltage Rating (AC) 250V
Max Current Rating 16A
Connector Style IEC 320-C20
Number of Ports 1
Current 20A
Voltage - IEC 250VAC
Filter Type Unfiltered - Commercial
Current - IEC 16A
Accomodates a Fuse No
Dimensions
Length 27mm
Panel Thickness 0.039 1.00mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
