PX0580/PC/7/LC
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
AC Power Entry Modules PCB FLANGE R/M INLET PC SPILLS W/TOP TAB
PDF
/
Buying Options
Total Price: USD $3.58
Unit Price: USD $3.5816
≥1 USD $3.5816
≥10 USD $3.24808
≥100 USD $3.07648
≥500 USD $3.005024
≥1000 USD $2.861936
≥3000 USD $2.504198
Inventory: 278
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 24 Weeks
Physical
Contact Material Brass
Contact Plating Nickel
Mount Through Hole
Mounting Type Panel Mount, Flange; Through Hole, Right Angle
Housing Material Nylon
Technical
Packaging Bulk
Published 2005
Series PX
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Receptacle, Male Blades
Number of Positions 3
Max Operating Temperature 70°C
Min Operating Temperature -40°C
Color Black
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Option GENERAL PURPOSE
Total Number of Contacts 3
Orientation Right Angle
Depth 23.7mm
Approval Agency CSA, ENEC, UL, VDE
Mating Information MULTIPLE MATING PARTS AVAILABLE
Panel Cutout Dimensions Rectangular - 30.25mm x 22.48mm
Body/Shell Style PLUG
Max Voltage Rating (AC) 250V
Max Current Rating 10A
Coupling Type SNAP
Connector Style IEC 320-C14
Number of Ports 1
Current - UL 15A
Voltage - IEC 250VAC
Filter Type Unfiltered - Commercial
Accomodates a Fuse No
Dimensions
Length 49.8mm
Panel Thickness 0.126 3.20mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
