PF0011/20/48
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
Plug C14 Faston 4.8 x 0.8 mm 10 A/250 VAC black Snap-in L + N + PE, PF0011/20/48, Bulgin
PDF
/
Buying Options
Total Price: USD $5.78
Unit Price: USD $5.781197
≥1 USD $5.781197
≥10 USD $5.453962
≥100 USD $5.145244
≥500 USD $4.854003
≥1000 USD $4.579253
Inventory: 6825
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Panel Thickness 0.079 2.00mm
Length 31mm
Technical
Fuse Holder, Drawer Drawer Included
Accomodates a Fuse Yes (Fuse Not Included)
Filter Type Unfiltered - Commercial
Voltage - IEC 250VAC
Number of Ports 1
Connector Style IEC 320-C14
Max Current Rating 10A
Max Voltage Rating (AC) 250V
Panel Cutout Dimensions Rectangular - 27.30mm x 31.12mm
Mating Information MULTIPLE MATING PARTS AVAILABLE
Approval Agency CSA, ENEC, UL, VDE
Depth 30.5mm
Orientation Straight
Total Number of Contacts 3
Option GENERAL PURPOSE
IEC Conformance YES
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating TIN
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 70°C
Number of Positions 3
Connector Type Receptacle, Male Blades - Module
Termination Quick Connect - 0.189 (4.8mm)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series PF
Published 2015
Packaging Bulk
Physical
Housing Material Nylon
Shell Material POLYAMIDE
Package / Case Module
Mounting Type Panel Mount, Snap-In
Contact Material BRASS
Supply Chain
Factory Lead Time 24 Weeks
