PF0011/15/63
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
PWR ENT MOD RCPT IEC320-C14 PNL
PDF
/
Buying Options
Total Price: USD $8.61
Unit Price: USD $8.6064
≥1 USD $8.6064
≥10 USD $7.74576
≥100 USD $7.296608
≥500 USD $7.10952
≥1000 USD $6.922432
≥3000 USD $6.174062
Inventory: 249
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 24 Weeks
Physical
Contact Material Brass
Contact Plating Tin
Mount Panel, Snap in
Mounting Type Panel Mount, Snap-In
Package / Case Module
Shell Material POLYAMIDE
Housing Material Nylon
Technical
Packaging Bulk
Published 2000
Series PF
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Quick Connect - 0.250 (6.3mm)
Connector Type Receptacle, Male Blades - Module
Number of Positions 3
Max Operating Temperature 70°C
Min Operating Temperature -40°C
Color Black
Gender Male
Voltage - Rated DC 250V
Contact Finish - Mating TIN
MIL Conformance NO
DIN Conformance NO
IEC Conformance YES
Option GENERAL PURPOSE
Total Number of Contacts 3
Orientation Straight
Depth 32.6mm
Current Rating 10A
Voltage - Rated AC 250V
Approval Agency CSA, ENEC, UL, VDE
Panel Cutout Dimensions Rectangular - 27.30mm x 31.12mm
Max Voltage Rating (AC) 250V
Max Current Rating 10A
Connector Style IEC 320-C14
Number of Ports 1
Voltage - IEC 250VAC
Filter Type Unfiltered - Commercial
Accomodates a Fuse Yes (Fuse Not Included)
Fuse Yes
Fuse Holder, Drawer Drawer Included
Dimensions
Length 31mm
Panel Thickness 0.059 1.50mm
Compliance
Material Flammability Rating UL94 V-0
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
