68-BSF-040-0-11
RoHS
/
Package Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
Switch On-Off 68-BSF RoHS Compliant GENERAL PURPOSE Power Entry Connector Receptacle, Male Blades - Module 4A 250VAC 787.4mum
PDF
/
Inventory: 9120
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Flanges, Panel
Mounting Type Panel Mount, Flange
Package / Case Module
Shell Material METAL
Technical
Packaging Tray
Series 68-BSF
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Quick Connect - 0.250 (6.3mm)
ECCN Code EAR99
Connector Type Receptacle, Male Blades - Module
Number of Positions 3
Additional Feature STANDARD: UL, EMI SHIELDED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Option GENERAL PURPOSE
Total Number of Contacts 3
Approval Agency CSA, SEMKO, UL
Panel Cutout Dimensions Rectangular - 29.46mm x 60.93mm
Coupling Type SNAP
Connector Style IEC 320-C14
Current 4A
Voltage - UL 250VAC
Filter Type Filtered (EMI, RFI) - Commercial
Accomodates a Fuse Yes (Fuse Not Included)
Fuse Yes
Fuse Holder, Drawer Drawer Included, Twin Fused
Switch Features Switch On-Off
Dimensions
Panel Thickness 787.4μm
Compliance
RoHS Status RoHS Compliant
