64-BSF-020-3-06
RoHS
/
Package Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
Power Entry Module Filtered M 3 POS 250VAC 2A Switch/Fuse ST 1 Port
PDF
/
Inventory: 5933
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length 65mm
Technical
Fuse Holder, Drawer Drawer Included
Fuse Yes
Accomodates a Fuse Yes (Fuse Not Included)
Filter Type Filtered (EMI, RFI) - Commercial
Voltage - UL 250VAC
Current 2A
Number of Ports 1
Connector Style IEC 320-C14
Coupling Type SNAP
Max Current Rating 2A
Max Voltage Rating (AC) 250V
Panel Cutout Dimensions Rectangular - 29.50mm x 61.00mm
Approval Agency CSA, TUV, UL
Depth 57.8mm
Orientation Straight
Total Number of Contacts 3
Option GENERAL PURPOSE
IEC Conformance YES
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Additional Feature STANDARDS: UL; CSA; VDE
Min Operating Temperature -25°C
Max Operating Temperature 85°C
Number of Positions 3
Connector Type Receptacle, Male Blades - Module
ECCN Code EAR99
Termination Solder Eyelet
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Series 64-BSF
Published 2014
Packaging Tray
Physical
Shell Material METAL
Package / Case Module
Mounting Type Panel Mount, Flange
Mount Flanges, Panel
