STGIB8CH60TS-E
RoHS
/
Package 26-PowerDIP Module (1.327, 33.70mm)
Category Discrete Semiconductor Products / Power Driver Modules
Description
SLLIMM
PDF
/
Inventory: 3965
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 24mm
Length 38mm
Technical
Current 12A
Voltage 600V
Configuration 3 Phase Inverter
Temperature Grade AUTOMOTIVE
Voltage - Isolation 1500Vrms
Operating Temperature (Min) -40°C
Operating Temperature (Max) 125°C
JESD-30 Code R-XZFM-T26
Base Part Number STGIB8
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 15V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position ZIG-ZAG
Type IGBT
Number of Terminations 26
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series SLLIMM?
Physical
Surface Mount NO
Package / Case 26-PowerDIP Module (1.327, 33.70mm)
Mounting Type Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Factory Lead Time 26 Weeks
