BM63364S-VA
RoHS
RoHS compliant
RoHS compliantPackage 25-PowerDIP Module (1.134, 28.80mm)
Category Discrete Semiconductor Products / Power Driver Modules
Description
25-PowerDIP Module (1.134 28.80mm) Through Hole IGBT 3Phase Inverter Power Driver Module 15A 600V 125C
PDF
/
Buying Options
Total Price: USD $19.93
Unit Price: USD $19.932
≥1 USD $19.932
≥10 USD $16.52464
≥100 USD $15.49181
≥500 USD $13.21965
Inventory: 151
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Technical
Current 15A
Voltage 600V
Configuration 3 Phase Inverter
Temperature Grade INDUSTRIAL
Voltage - Isolation 1500Vrms
Operating Temperature (Min) -25°C
Operating Temperature (Max) 125°C
JESD-30 Code R-XDFM-T24
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 15V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Technology HYBRID
HTS Code 8542.39.00.01
Type IGBT
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2014
Physical
Surface Mount NO
Package / Case 25-PowerDIP Module (1.134, 28.80mm)
Mounting Type Through Hole
Supply Chain
Factory Lead Time 13 Weeks
