BM63363S-VA
RoHS
RoHS compliant
RoHS compliantPackage 25-PowerDIP Module (1.134, 28.80mm)
Category Discrete Semiconductor Products / Power Driver Modules
Description
IC IPM 600V IGBT SW 25HSDIP
PDF
/
Buying Options
Total Price: USD $17.26
Unit Price: USD $17.2568
≥1 USD $17.2568
≥10 USD $14.30616
≥100 USD $13.41201
≥500 USD $11.444902
Inventory: 113
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mounting Type Through Hole
Package / Case 25-PowerDIP Module (1.134, 28.80mm)
Surface Mount NO
Technical
Published 2014
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 24
Type IGBT
HTS Code 8542.39.00.01
Technology HYBRID
Terminal Position DUAL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 15V
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-XDFM-T24
Operating Temperature (Max) 125°C
Operating Temperature (Min) -25°C
Voltage - Isolation 1500Vrms
Temperature Grade INDUSTRIAL
Configuration 3 Phase Inverter
Voltage 600V
Current 10A
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
