PS12032
RoHS
/
Package 28-PowerDIP Module (2.717, 69.00mm)
Category Discrete Semiconductor Products / Power Driver Modules
Description
Intellimod? 28-PowerDIP Module (2.717 69.00mm) Through Hole IGBT Power Driver Module 5A 1.2kV
PDF
/
Inventory: 2403
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case 28-PowerDIP Module (2.717, 69.00mm)
Surface Mount NO
Technical
Published 2002
Series Intellimod?
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
ECCN Code EAR99
Type IGBT
HTS Code 8542.39.00.01
Subcategory Motion Control Electronics
Technology HYBRID
Terminal Position UPPER
Terminal Form UNSPECIFIED
Number of Functions 1
Supply Voltage 15V
Reach Compliance Code unknown
JESD-30 Code R-XUFM-X28
Qualification Status Not Qualified
Voltage - Isolation 2500VDC
Power Supplies 15600V
Configuration 3 Phase
Voltage 1.2kV
Current 5A
Compliance
RoHS Status Non-RoHS Compliant
