PM75B4LB060

Powerex Inc.
RoHS
/
Package Power Module
Category Discrete Semiconductor Products / Power Driver Modules
Description Intellimod? Power Module Chassis Mount IGBT Power Driver Module 75A 600V
PDF
/
Inventory: 1235
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Technical

Current 75A
Voltage 600V
Configuration H-Bridge
Voltage - Isolation 2500VDC
Qualification Status Not Qualified
JESD-30 Code R-XXMA-X25
Reach Compliance Code unknown
Supply Voltage 15V
Number of Functions 1
Terminal Form UNSPECIFIED
Terminal Position UNSPECIFIED
Technology HYBRID
HTS Code 8542.39.00.01
Type IGBT
ECCN Code EAR99
Number of Terminations 25
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series Intellimod?
Published 2005

Physical

Surface Mount NO
Package / Case Power Module
Mounting Type Chassis Mount
