PM100CVA120
RoHS
/
Package Power Module
Category Discrete Semiconductor Products / Power Driver Modules
Description
MOD IPM 6PAC 1200V 100A
PDF
/
Buying Options
Total Price: USD $127.61
Unit Price: USD $127.61255
≥1 USD $127.61255
≥10 USD $123.35845
≥100 USD $110.5971
Inventory: 1308
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Chassis Mount
Package / Case Power Module
Technical
Published 1998
Series Intellimod?
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 19
ECCN Code EAR99
Type IGBT
HTS Code 8542.39.00.01
Subcategory Motion Control Electronics
Technology HYBRID
Number of Functions 1
Supply Voltage 15V
Reach Compliance Code unknown
Pin Count 24
Qualification Status Not Qualified
Voltage - Isolation 2500Vrms
Power Supplies 15V
Configuration 3 Phase
Voltage 1.2kV
Current 100A
Power Dissipation 595W
Compliance
RoHS Status RoHS Compliant
