FSBS5CH60
RoHS
/
Package 27-PowerDIP Module (1.205, 30.60mm)
Category Discrete Semiconductor Products / Power Driver Modules
Description
Motor / Motion / Ignition Controllers & Drivers HIGH POWER
PDF
/
Buying Options
Total Price: USD $18.93
Unit Price: USD $18.9288
≥1 USD $18.9288
Inventory: 254
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status LAST SHIPMENTS (Last Updated: 2 days ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 27-PowerDIP Module (1.205, 30.60mm)
Number of Pins 27
Weight 13.86g
Technical
Published 2007
Series Motion SPM? 3
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 27
ECCN Code EAR99
Type IGBT
Terminal Finish Tin (Sn)
Max Operating Temperature 125°C
Min Operating Temperature -20°C
HTS Code 8541.29.00.95
Technology HYBRID
Terminal Position DUAL
Number of Functions 1
Supply Voltage 15V
Number of Outputs 3
Voltage - Isolation 2500Vrms
Output Voltage 300V
Operating Supply Voltage 16.5V
Configuration 3 Phase
Max Current Rating 5A
Nominal Supply Current 100μA
Power Dissipation 25W
Output Current 10A
Collector Emitter Voltage (VCEO) 2.3V
Max Collector Current 5A
Collector Emitter Breakdown Voltage 600V
Min Breakdown Voltage 600V
Dimensions
Height 5.5mm
Length 44mm
Width 26.8mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
Alternative Model
