FSBB30CH60CT
RoHS
RoHS compliant
RoHS compliantPackage 27-PowerDIP Module (1.205, 30.60mm)
Category Discrete Semiconductor Products / Power Driver Modules
Description
MODULE SPM 600V 30A SPMEC
PDF
/
Buying Options
Total Price: USD $26.31
Unit Price: USD $26.3112
≥1 USD $26.3112
≥10 USD $21.58875
≥100 USD $20.91425
≥500 USD $20.23975
≥1000 USD $19.56525
Inventory: 1764
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 27-PowerDIP Module (1.205, 30.60mm)
Number of Pins 27
Weight 21.978g
Technical
Published 2014
Series Motion SPM? 3
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 27
Type IGBT
Terminal Finish Tin (Sn)
Max Operating Temperature 150°C
Min Operating Temperature -40°C
Subcategory Motion Control Electronics
Terminal Position DUAL
Number of Functions 1
Supply Voltage 300V
Base Part Number FSBB30CH60
Qualification Status Not Qualified
Voltage - Isolation 2500Vrms
Operating Supply Voltage 400V
Power Supplies 15V
Configuration 3 Phase
Max Supply Voltage 450V
Max Current Rating 30A
Nominal Supply Current 500μA
Power Dissipation 103W
Output Current-Max 60A
Supply Current-Max (Isup) 23mA
Collector Emitter Voltage (VCEO) 2.6V
Max Collector Current 30A
Min Breakdown Voltage 600V
Dimensions
Height 5.7mm
Length 44.2mm
Width 27mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
