FSBB20CH60L

ON Semiconductor
RoHS
RoHS RoHS compliant
Package 27-PowerDIP Module (1.205, 30.60mm)
Category Discrete Semiconductor Products / Power Driver Modules
Description SPM? 27-PowerDIP Module (1.205 30.60mm) Through Hole IGBT Power Driver Module 20A 2.3V 125C
PDF
/
Buying Options
Total Price: USD $34.58
Unit Price: USD $34.584
≥1 USD $34.584
Inventory: 207
Minimum: 1
-
+

Technical Details

Physical

Mount Through Hole
Mounting Type Through Hole
Package / Case 27-PowerDIP Module (1.205, 30.60mm)
Number of Pins 27
Weight 21.978g

Technical

Published 2007
Series SPM?
JESD-609 Code e3
Pbfree Code yes
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 27
ECCN Code EAR99
Type IGBT
Terminal Finish MATTE TIN
Max Operating Temperature 125°C
Min Operating Temperature -20°C
HTS Code 8541.29.00.95
Terminal Position DUAL
Number of Functions 1
Supply Voltage 15V
Base Part Number FSBB20CH60
Voltage - Isolation 2500Vrms
Supply Voltage-Max (Vsup) 16.5V
Supply Voltage-Min (Vsup) 13.5V
Configuration 3 Phase
Max Current Rating 20A
Output Current-Max 40A
Collector Emitter Voltage (VCEO) 2.3V
Min Breakdown Voltage 600V

Dimensions

Height 5.5mm
Length 44mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
