FSB70550
RoHS
RoHS compliant
RoHS compliantPackage 27-PowerLQFN Module
Category Discrete Semiconductor Products / Power Driver Modules
Description
Motor / Motion / Ignition Controllers & Drivers SPM
PDF
/
Buying Options
Total Price: USD $5.07
Unit Price: USD $5.0688
≥1 USD $5.0688
Inventory: 984
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Min Breakdown Voltage 500V
Drain to Source Resistance 1.85Ohm
Output Current 5.3A
Operating Supply Current 1.7mA
Max Current Rating 5.3A
Configuration 3 Phase
Power Supplies 15V
Operating Supply Voltage 300V
Voltage - Isolation 1500Vrms
Qualification Status Not Qualified
Number of Outputs 3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 15kHz
Reach Compliance Code not_compliant
Supply Voltage 15V
Peak Reflow Temperature (Cel) 260
Max Power Dissipation 110W
Subcategory Motion Control Electronics
HTS Code 8541.29.00.95
Min Operating Temperature -40°C
Max Operating Temperature 150°C
Terminal Finish Tin (Sn)
Type MOSFET
ECCN Code EAR99
Number of Terminations 27
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series Motion SPM? 7
Published 2016
Packaging Tape & Reel (TR)
Physical
Weight 2.174663g
Number of Pins 27
Package / Case 27-PowerLQFN Module
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 12 Weeks
