FSB70325
RoHS
RoHS compliant
RoHS compliantPackage 27-PowerLQFN Module
Category Discrete Semiconductor Products / Power Driver Modules
Description
MODULE SPM 250V 4.1A 27-QFN
PDF
/
Buying Options
Total Price: USD $4.48
Unit Price: USD $4.4792
≥1 USD $4.4792
Inventory: 1969
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 13mm
Length 13mm
Height 1.4mm
Technical
Min Breakdown Voltage 250V
Switching Frequency 15kHz
Max Collector Current 4.1A
Collector Emitter Voltage (VCEO) 250V
Output Current 5mA
Operating Supply Current 1.7mA
Max Current Rating 4.1A
Max Supply Voltage 200V
Configuration 3 Phase
Power Supplies 15V
Operating Supply Voltage 150V
Voltage - Isolation 1500Vrms
Qualification Status Not Qualified
Number of Outputs 3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 15kHz
Reach Compliance Code not_compliant
Supply Voltage 150V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position UNSPECIFIED
Technology HYBRID
Max Power Dissipation 49W
Subcategory Motion Control Electronics
HTS Code 8541.29.00.95
Min Operating Temperature -40°C
Max Operating Temperature 150°C
Terminal Finish Tin (Sn)
Type MOSFET
ECCN Code EAR99
Number of Terminations 30
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series Motion SPM? 7
Published 2014
Packaging Tape & Reel (TR)
Physical
Weight 2.174663g
Number of Pins 27
Package / Case 27-PowerLQFN Module
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 6 Weeks
