FSB50825B
RoHS
RoHS compliant
RoHS compliantPackage 23-PowerDIP Module (0.551, 14.00mm)
Category Discrete Semiconductor Products / Power Driver Modules
Description
IC MODULE MOTION SPM5P-023
PDF
/
Buying Options
Total Price: USD $4.02
Unit Price: USD $4.016988
≥1 USD $4.016988
≥10 USD $1.554291
≥100 USD $1.50012
≥500 USD $1.473729
Inventory: 1468
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 12mm
Length 29mm
Height Seated (Max) 3.3mm
Technical
Current 3.6A
Voltage 250V
Configuration 3 Phase Inverter
Temperature Grade AUTOMOTIVE
Voltage - Isolation 1500Vrms
Operating Temperature (Min) -40°C
Operating Temperature (Max) 125°C
JESD-30 Code R-XDMA-T23
Supply Voltage 15V
Number of Functions 1
Terminal Position DUAL
Technology HYBRID
Type MOSFET
Number of Terminations 23
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
Series Motion SPM? 5
Physical
Surface Mount NO
Package / Case 23-PowerDIP Module (0.551, 14.00mm)
Mounting Type Through Hole
Supply Chain
Factory Lead Time 8 Weeks
