FSAM15SM60A
RoHS
/
Package 32-PowerDIP Module (1.370, 34.80mm)
Category Discrete Semiconductor Products / Power Driver Modules
Description
Motion SPM? 2 32-PowerDIP Module (1.370 34.80mm) Through Hole IGBT Power Driver Module 15A 50W 830ns 600V
PDF
/
Buying Options
Total Price: USD $19.92
Unit Price: USD $19.9232
≥1 USD $19.9232
Inventory: 210
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 34.8mm
Length 60mm
Height 7.2mm
Technical
Min Breakdown Voltage 600V
Collector Emitter Breakdown Voltage 600V
Collector Emitter Voltage (VCEO) 2.3V
Turn-Off Delay Time 830 ns
Nominal Input Voltage 253V
Turn On Delay Time 320 ns
Output Current 30A
Power Dissipation 50W
Nominal Supply Current 26mA
Max Current Rating 15A
Configuration 3 Phase
Supply Voltage-Min (Vsup) 13.5V
Temperature Grade AUTOMOTIVE
Supply Voltage-Max (Vsup) 16.5V
Operating Supply Voltage 300V
Output Voltage 600V
Voltage - Isolation 2500Vrms
Base Part Number FSAM15
Supply Voltage 15V
Number of Functions 1
Terminal Position DUAL
Technology HYBRID
Min Operating Temperature -20°C
Max Operating Temperature 125°C
Type IGBT
Number of Terminations 32
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series Motion SPM? 2
Published 2011
Physical
Weight 32.58g
Number of Pins 32
Package / Case 32-PowerDIP Module (1.370, 34.80mm)
Mounting Type Through Hole
Mount Through Hole
