FNB43060T2
RoHS
RoHS compliant
RoHS compliantPackage 26-PowerDIP Module (1.024, 26.00mm)
Category Discrete Semiconductor Products / Power Driver Modules
Description
FAIRCHILD SEMICONDUCTOR FNB43060T2 SMART POWER MODULE, 2KV, SPMAB-C26New
PDF
/
Buying Options
Total Price: USD $16.65
Unit Price: USD $16.6459
≥1 USD $16.6459
≥10 USD $13.65815
≥100 USD $13.2316
≥500 USD $12.80505
≥1000 USD $12.37755
Inventory: 13512
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Technical
Min Breakdown Voltage 600V
Collector Emitter Voltage (VCEO) 2.25V
Output Current-Max 60A
Max Current Rating 30A
Configuration 3 Phase
Temperature Grade AUTOMOTIVE
Supply Voltage-Max (Vsup) 400V
Voltage - Isolation 2000Vrms
JESD-30 Code R-XDFM-T26
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Supply Voltage 300V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Technology HYBRID
Additional Feature CONTROL SUPPLY VOLTAGE(VCC)= 15V
Min Operating Temperature -40°C
Max Operating Temperature 150°C
Terminal Finish Tin (Sn)
Type IGBT
Number of Terminations 26
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series Motion SPM? 45
Published 2012
Physical
Weight 17.088g
Package / Case 26-PowerDIP Module (1.024, 26.00mm)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 8 Weeks
