FNB41060B2

ON Semiconductor
RoHS
RoHS RoHS compliant
Package 26-PowerDIP Module (1.024, 26.00mm)
Category Discrete Semiconductor Products / Power Driver Modules
Description Power Driver Module IGBT 3 Phase 600V 10A Module
PDF
/
Buying Options
Total Price: USD $13.44
Unit Price: USD $13.4376
≥1 USD $13.4376
≥10 USD $11.83893
≥100 USD $10.238967
≥500 USD $9.279072
≥1000 USD $8.511149
Inventory: 108
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width 23mm
Length 39mm
Height Seated (Max) 7.5mm

Technical

Min Breakdown Voltage 600V
Collector Emitter Voltage (VCEO) 2V
Output Current-Max 15A
Max Current Rating 10A
Configuration 3 Phase
Supply Voltage-Min (Vsup) 13.5V
Supply Voltage-Max (Vsup) 16.5V
Voltage - Isolation 2000Vrms
JESD-30 Code R-PDIP-T26
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Supply Voltage 15V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
HTS Code 8541.29.00.95
Min Operating Temperature -40°C
Max Operating Temperature 150°C
Terminal Finish Tin (Sn)
Type IGBT
ECCN Code EAR99
Number of Terminations 26
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series Motion SPM? 45
Published 2017

Physical

Weight 17.088g
Package / Case 26-PowerDIP Module (1.024, 26.00mm)
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 8 Weeks
