IGCM20F60HAXKMA1
RoHS
/
Package 24-PowerDIP Module (1.028, 26.10mm)
Category Discrete Semiconductor Products / Power Driver Modules
Description
Trans IGBT Module N-CH 24-Pin MDIP
PDF
/
Inventory: 4460
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 24-PowerDIP Module (1.028, 26.10mm)
Number of Pins 24
Technical
Published 2015
Series CIPOS?
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 24
ECCN Code EAR99
Type IGBT
Max Operating Temperature 150°C
Min Operating Temperature -40°C
HTS Code 8542.39.00.01
Terminal Position DUAL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 16V
Current Rating 20A
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Collector Emitter Voltage (VCEO) 600V
Halogen Free Halogen Free
Power Dissipation 2.5kW
Current 20A
Configuration 3 Phase
Supply Voltage-Min (Vsup) 14V
Temperature Grade INDUSTRIAL
Supply Voltage-Max (Vsup) 18.5V
Voltage - Isolation 2000Vrms
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 21mm
Length 36mm
Height Seated (Max) 5.6mm
Alternative Model
