IFCM15S60GDXKMA1
RoHS
RoHS compliant
RoHS compliantPackage 24-PowerDIP Module (1.028, 26.10mm)
Category Discrete Semiconductor Products / Power Driver Modules
Description
IFPS MODULES
PDF
/
Buying Options
Total Price: USD $13.96
Unit Price: USD $13.962228
≥1 USD $13.962228
≥10 USD $5.40321
≥100 USD $5.212917
≥500 USD $5.119854
Inventory: 1179
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mounting Type Through Hole
Package / Case 24-PowerDIP Module (1.028, 26.10mm)
Surface Mount NO
Technical
Published 2017
Series CIPOS?
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 24
ECCN Code EAR99
Type IGBT
HTS Code 8542.39.00.01
Technology HYBRID
Terminal Position DUAL
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 16V
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-MDFM-X24
Operating Temperature (Max) 125°C
Operating Temperature (Min) -40°C
Voltage - Isolation 2000Vrms
Output Voltage 600V
Temperature Grade AUTOMOTIVE
Configuration 3 Phase Inverter
Voltage 650V
Current 30A
Output Current 15A
Compliance
RoHS Status ROHS3 Compliant
