ST4ETB203

Vishay
RoHS
/
Package /
Category / Potentiometers, Variable Resistors
Description Trimmer Resistors - SMD 4mm SQ 20Kohms
PDF
/
Inventory: 8754
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status Non-RoHS Compliant

Dimensions

Width 4.5mm
Length 5.2mm
Height 2.3mm

Technical

Rotation Angle 3600 deg
Actuator Orientation VERTICAL
Number of Turns 1
Rated Temperature 70°C
Size Code 2420
Working Voltage 70.7V
Operating Temperature (Min) -55°C
Actuator Type SCREW
Operating Temperature (Max) 125°C
Rated Power Dissipation (P) 0.25W
Resistor Type TRIMMER
Construction Sealed
Technology CERMET
Packing Method TR, EMBOSSED, 7 INCH
Power Rating 250mW
Subcategory Variable Resistors
HTS Code 8533.40.80.50
Color Black
Terminal Finish Tin/Copper (Sn/Cu)
Resistance 20kOhm
Temperature Coefficient -100100 ppm/°C
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 3
Pbfree Code yes
JESD-609 Code e2
Tolerance 20%
Series ST-4

Physical

Weight 120mg
Mounting Feature SURFACE MOUNT
Terminal Shape GULL WING
Surface Mount YES
