MCP4231T502EMF

Microchip Technology
RoHS
/
Package DFN
Category / Potentiometers, Variable Resistors
Description
PDF
/
Inventory: 7730
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Package / Case DFN
Surface Mount YES

Technical

Packaging Tape & Reel
JESD-609 Code e3
Pbfree Code yes
Moisture Sensitivity Level (MSL) 1
Number of Terminations 10
ECCN Code EAR99
Temperature Coefficient 150 ppm/°C
Resistance 5kOhm
Number of Positions 128
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
HTS Code 8542.39.00.01
Technology CMOS
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) 40
Pin Count 10
JESD-30 Code S-PDSO-N10
Operating Supply Voltage 5V
Temperature Grade AUTOMOTIVE
Max Supply Voltage 5.5V
Min Supply Voltage 1.8V
Nominal Supply Current 1mA
Memory Type Volatile
Converter Type DIGITAL POTENTIOMETER
Bandwidth 2 kHz
Total Resistance 5000Ohm
Resistor Terminal Voltage-Max 5V
Control Interface INCREMENT/DECREMENT

Dimensions

Height Seated (Max) 1mm
Length 3mm
Width 3mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
