H-1200

Bourns Inc.
RoHS
RoHS RoHS compliant
Package /
Category Kits / Potentiometer Kits
Description Resistor Kits Premium and Vintage Guitar Pot Kit
PDF
/
Inventory: 4995
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC No SVHC

Technical

Kit Type Rotary
Quantity 24 Pieces (12 Values - 2 Each)
Rotation Angle 260 deg
Actuator Orientation VERTICAL
Taper Logarithmic
Number of Turns 1
Rated Temperature 85°C
Lead Diameter 0.46 mm
Working Voltage 300V
Lead Length 6.78mm
Actuator Type SCREW
Rated Power Dissipation (P) 0.5W
Termination Style Solder Hook
Resistor Type TRIMMER
Construction Trimmer Pot
Technology CERMET
Packing Method TUBE
Power Rating 250mW
Subcategory POTENTIOMETER
Power (Watts) 1/4W
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Matte Tin (Sn)
Resistance 250k~500kOhm
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance ±10% ±20%
Series 82, 95
Published 2011
Packaging Plastic Box with Bin Guide

Physical

Resistive Material Conductive Plastic
Mounting Feature THROUGH HOLE MOUNT
Terminal Shape WIRE
Surface Mount NO

Supply Chain

Factory Lead Time 7 Weeks
