ZMID5201AE1T image
Favorite
ZMID5201AE1T image
Favorite
RoHS
RoHS RoHS compliant
Package 14-TSSOP (0.173, 4.40mm Width)
Category Sensors, Transducers / Position Sensors - Angle, Linear Position Measuring
Description SENSOR ROTARY 360DEG SMD
PDF
/
Buying Options
Total Price: USD $6.02
Unit Price: USD $6.022272
≥1 USD $6.022272
≥200 USD $2.330398
≥500 USD $2.248998
≥1000 USD $2.208298
Inventory: 5821
Minimum: 1
-
+

Technical Details

Physical

Mounting Type Surface Mount
Package / Case 14-TSSOP (0.173, 4.40mm Width)

Technical

Operating Temperature -40°C~150°C
Packaging Tube
Series Automotive, AEC-Q100
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Technology Inductive
Voltage - Supply 4.5V~5.5V
Output Analog Voltage
Termination Style Gull Wing
Actuator Type Inductive Target
For Measuring Linear, Rotary Position
Output Signal Clockwise Increase
Rotation Angle - Electrical, Mechanical 0° ~ 360°

Compliance

RoHS Status ROHS3 Compliant
