AAT009-10E
RoHS
RoHS compliant
RoHS compliantPackage 6-WDFN Exposed Pad
Category Sensors, Transducers / Position Sensors - Angle, Linear Position Measuring
Description
SENSOR ANGLE 360DEG SMD
PDF
/
Buying Options
Total Price: USD $6.29
Unit Price: USD $6.292
≥1 USD $6.292
≥10 USD $4.71944
≥100 USD $4.195136
≥500 USD $3.985344
≥1000 USD $3.880536
≥3000 USD $3.25123
Inventory: 941
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Surface Mount
Package / Case 6-WDFN Exposed Pad
Surface Mount YES
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2016
Series AAT
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
Resistance 10MOhm
HTS Code 8542.39.00.01
Technology Magnetoresistive
Voltage - Supply 5.5V
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Output Resistive
Termination Style SMD (SMT) Tab
JESD-30 Code S-PDSO-N6
Actuator Type External Magnet, Not Included
Supply Voltage-Max (Vsup) 5.5V
Analog IC - Other Type ANALOG CIRCUIT
For Measuring Angle
Rotation Angle - Electrical, Mechanical 0° ~ 360°, Continuous
Dimensions
Height Seated (Max) 0.8mm
Length 2.5mm
Width 2.5mm
Compliance
RoHS Status ROHS3 Compliant
