SV01A103AEA01B00
RoHS
RoHS compliant
RoHS compliantPackage 4-SMD, Gull Wing
Category Sensors, Transducers / Position Sensors - Angle, Linear Position Measuring
Description
SENSOR ROTARY 333.3DEG SMD
PDF
/
Buying Options
Total Price: USD $1.81
Unit Price: USD $1.80534
≥1 USD $1.80534
≥10 USD $1.70315
≥100 USD $1.60675
≥500 USD $1.5158
≥1000 USD $1.43
Inventory: 5000
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 4-SMD, Gull Wing
Weight 360mg
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Series SV01
Tolerance 30%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Gull Wing
Temperature Coefficient 500 ppm/°C
Resistance 10kOhm
Power Rating 300mW
Technology Resistive
Depth 14.9mm
Military Standard Not
Output Analog Voltage
Termination Style SMD (SMT) Tab
Actuator Type Hole for Shaft
Number of Turns 1
Linearity ±2%
Resistance Tolerance ±30%
For Measuring Rotary Position
Rotation Angle - Electrical, Mechanical 0° ~ 333.3°, Continuous
Dimensions
Height 3.1mm
Length 11mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
