MLX90324LDC-DBO-100-RE
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Sensors, Transducers / Position Sensors - Angle, Linear Position Measuring
Description
IC SENSOR INTERFACE ROTARY 8SOIC
PDF
/
Buying Options
Total Price: USD $3.41
Unit Price: USD $3.409601
≥1 USD $3.409601
≥200 USD $1.319465
≥500 USD $1.273513
≥1000 USD $1.251194
Inventory: 1138
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Body Height 1.62mm
Technical
Rotation Angle - Electrical, Mechanical 0° ~ 360°, Continuous
For Measuring Rotary Position
Sensing Method Hall Effect
Linearity ±1°
Response Time 660 μs
Actuator Type External Magnet, Not Included
Body Breadth 3.9 mm
Body Length or Diameter 4.89mm
Termination Style Gull Wing
Output SENT
Voltage - Supply 4.5V~5.5V
Technology Hall Effect
Terminal Finish Matte Tin (Sn)
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e3
Series Triaxis?
Published 2007
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C
Physical
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 21 Weeks
