TLE5309DE5201XUMA1
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.154, 3.90mm Width)
Category Sensors, Transducers / Position Sensors - Angle, Linear Position Measuring
Description
POSITION&CURRENT SENSORS
PDF
/
Buying Options
Total Price: USD $3.37
Unit Price: USD $3.371527
≥1 USD $3.371527
≥200 USD $1.305023
≥500 USD $1.259071
≥1000 USD $1.236752
Inventory: 1179
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 5mm
Height Seated (Max) 1.2mm
Technical
Rotation Angle - Electrical, Mechanical 0° ~ 360°, Continuous
Output Signal Cosine, Sine
For Measuring Angle
Analog IC - Other Type ANALOG CIRCUIT
Supply Voltage-Min (Vsup) 3V
Supply Voltage-Max (Vsup) 3.6V
Actuator Type External Magnet, Not Included
JESD-30 Code R-PDSO-G16
Termination Style Gull Wing
Output Analog Voltage
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.65mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Voltage - Supply 3V~3.6V 4.5V~5.5V
Technology Magnetoresistive
HTS Code 8542.39.00.01
Additional Feature ALSO REQUIRE SUPPLY VDD, AMR RANGES FROM 4.5V TO 5.5V
Number of Terminations 16
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
Series Automotive, AEC-Q100
Published 2016
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TA
Physical
Surface Mount YES
Package / Case 16-TSSOP (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 39 Weeks
