TLE5309DE2211XUMA1
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.154, 3.90mm Width)
Category Sensors, Transducers / Position Sensors - Angle, Linear Position Measuring
Description
POSITION&CURRENT SENSORS
PDF
/
Buying Options
Total Price: USD $5.91
Unit Price: USD $5.9071
≥1 USD $5.9071
≥10 USD $4.8469
≥100 USD $4.6949
≥500 USD $4.54385
≥1000 USD $4.3928
Inventory: 1340
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 39 Weeks
Physical
Mounting Type Surface Mount
Package / Case 16-TSSOP (0.154, 3.90mm Width)
Technical
Operating Temperature -40°C~125°C TA
Packaging Tape & Reel (TR)
Published 2016
Series Automotive, AEC-Q100
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Technology Magnetoresistive
Voltage - Supply 3V~3.6V 4.5V~5.5V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Output Analog Voltage
Termination Style Gull Wing
Actuator Type External Magnet, Not Included
Analog IC - Other Type ANALOG CIRCUIT
For Measuring Angle
Output Signal Cosine, Sine
Rotation Angle - Electrical, Mechanical 0° ~ 360°, Continuous
Compliance
RoHS Status ROHS3 Compliant
