TLE5014SP16E0002XUMA1
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.154, 3.90mm Width)
Category Sensors, Transducers / Position Sensors - Angle, Linear Position Measuring
Description
GMR-BASED ANGLE SENSOR
PDF
/
Buying Options
Total Price: USD $6.15
Unit Price: USD $6.1512
≥1 USD $6.1512
≥10 USD $4.61032
≥100 USD $4.098336
≥500 USD $3.893296
≥1000 USD $3.790864
Inventory: 267
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Rotation Angle - Electrical, Mechanical 0° ~ 360°, Continuous
Output Signal Cosine, Sine
For Measuring Angle
Actuator Type External Magnet, Not Included
Termination Style Gull Wing
Output Wheatstone Bridge
Voltage - Supply 3V~5.5V
Technology Magnetoresistive
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Series Automotive, AEC-Q100
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TA
Physical
Package / Case 16-TSSOP (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 39 Weeks
