TLE5014P16DXUMA1
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.154, 3.90mm Width)
Category Sensors, Transducers / Position Sensors - Angle, Linear Position Measuring
Description
Tape & Reel (TR) Automotive AEC-Q100 Gull Wing PWM Magnetoresistive Sensor 4.2V~5.5V -40C~125C 0°-360°
PDF
/
Buying Options
Total Price: USD $9.22
Unit Price: USD $9.2224
≥1 USD $9.2224
≥10 USD $7.37704
≥100 USD $6.82352
≥500 USD $5.901456
≥1000 USD $5.532648
≥3000 USD $5.163805
Inventory: 1111
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Rotation Angle - Electrical, Mechanical 0° ~ 360°
Output Signal Cosine, Sine
For Measuring Angle, Linear, Rotary
Analog IC - Other Type ANALOG CIRCUIT
Actuator Type External Magnet, Not Included
Termination Style Gull Wing
Output PWM
Voltage - Supply 4.2V~5.5V
Technology Magnetoresistive
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Series Automotive, AEC-Q100
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Package / Case 16-TSSOP (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 39 Weeks
