TLE5012BE5020XUMA1
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Sensors, Transducers / Position Sensors - Angle, Linear Position Measuring
Description
Angle Sensor 360 8-Pin DSO
PDF
/
Buying Options
Total Price: USD $4.91
Unit Price: USD $4.9104
≥1 USD $4.9104
≥10 USD $3.68544
≥100 USD $3.275712
≥500 USD $3.111856
≥1000 USD $3.029928
≥3000 USD $2.538571
Inventory: 7381
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 4mm
Length 5mm
Height Seated (Max) 1.75mm
Technical
Rotation Angle - Electrical, Mechanical 0° ~ 360°, Continuous
Output Signal Cosine, Sine
For Measuring Angle
Analog IC - Other Type ANALOG CIRCUIT
Supply Voltage-Min (Vsup) 3V
Supply Voltage-Max (Vsup) 5.5V
Output Type Digital
Actuator Type External Magnet, Not Included
Termination Style Gull Wing
Output Wheatstone Bridge
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Voltage - Supply 3V~5.5V
Technology Magnetoresistive
Number of Terminations 8
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
Series Automotive, AEC-Q100
Published 2014
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C TJ
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 26 Weeks
