TLE5012BE1000XUMA1
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Sensors, Transducers / Position Sensors - Angle, Linear Position Measuring
Description
RotaryPosition Sensor 5.5V Automotive 8-Pin DSO Tape and Reel
PDF
/
Buying Options
Total Price: USD $1.99
Unit Price: USD $1.9874
≥1 USD $1.9874
≥10 USD $1.6302
≥100 USD $1.57985
≥500 USD $1.52855
≥1000 USD $1.4782
≥3000 USD $1.32525
Inventory: 56902
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~150°C
Packaging Cut Tape (CT)
Published 2006
Series Automotive, AEC-Q100
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 8
Termination SMD/SMT
Terminal Finish Tin (Sn)
Technology Magnetoresistive
Voltage - Supply 3V~5.5V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Output Wheatstone Bridge
Termination Style Gull Wing
Actuator Type External Magnet, Not Included
Operating Supply Voltage 5V
Supply Voltage-Min (Vsup) 3V
Interface SPI
Analog IC - Other Type ANALOG CIRCUIT
For Measuring Angle
Rotation Angle - Electrical, Mechanical 0° ~ 360°, Continuous
Dimensions
Height Seated (Max) 1.75mm
Length 5mm
Width 4mm
Compliance
RoHS Status ROHS3 Compliant
