TLE5009E2000FUMA1
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Sensors, Transducers / Position Sensors - Angle, Linear Position Measuring
Description
RotaryPosition Sensor 5.5V Automotive Tape and Reel
PDF
/
Buying Options
Total Price: USD $2.88
Unit Price: USD $2.8776
≥1 USD $2.8776
≥10 USD $2.15776
≥100 USD $1.9184
≥500 USD $1.82248
≥1000 USD $1.77452
≥3000 USD $1.486742
Inventory: 1404
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Rotation Angle - Electrical, Mechanical 0° ~ 360°, Continuous
Output Signal Cosine, Sine
For Measuring Angle
Analog IC - Other Type ANALOG CIRCUIT
Actuator Type External Magnet, Not Included
Termination Style Gull Wing
Output Analog Voltage
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Voltage - Supply 4.5V~5.5V
Technology Magnetoresistive
HTS Code 8542.39.00.01
Terminal Finish Tin (Sn)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series Automotive, AEC-Q100
Published 2010
Packaging Cut Tape (CT)
Operating Temperature -40°C~150°C
Physical
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 26 Weeks
