TLE5009E1000FUMA1
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Sensors, Transducers / Position Sensors - Angle, Linear Position Measuring
Description
RotaryPosition Sensor 5.5V Automotive 8-Pin DSO Tape and Reel
PDF
/
Buying Options
Total Price: USD $7.74
Unit Price: USD $7.7425
≥1 USD $7.7425
≥10 USD $6.35265
≥100 USD $6.1541
≥500 USD $5.95555
≥1000 USD $5.757
≥1000 USD $5.16135
Inventory: 1152
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 26 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~150°C
Packaging Cut Tape (CT)
Published 2012
Series Automotive, AEC-Q100
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Terminal Finish Tin (Sn)
Technology Magnetoresistive
Voltage - Supply 3V~3.6V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Output Analog Voltage
Termination Style Gull Wing
Actuator Type External Magnet, Not Included
Operating Supply Voltage 3.3V
Interface Analog
For Measuring Angle
Output Signal Cosine, Sine
Rotation Angle - Electrical, Mechanical 0° ~ 360°, Continuous
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
