TLE5009A16E2210XUMA1
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.154, 3.90mm Width)
Category Sensors, Transducers / Position Sensors - Angle, Linear Position Measuring
Description
IC HALL SENSOR LINEAR TDSO-16
PDF
/
Buying Options
Total Price: USD $1.19
Unit Price: USD $1.192113
≥1 USD $1.192113
≥10 USD $1.008307
≥30 USD $0.907214
≥100 USD $0.792992
≥500 USD $0.743101
≥1000 USD $0.719469
Inventory: 1193
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 39 Weeks
Physical
Mounting Type Surface Mount
Package / Case 16-TSSOP (0.154, 3.90mm Width)
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series Automotive, AEC-Q100
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Technology Magnetoresistive
Voltage - Supply 4.5V~5.5V
Output Analog Voltage
Termination Style Gull Wing
Actuator Type External Magnet, Not Included
For Measuring Angle
Output Signal Cosine, Sine
Rotation Angle - Electrical, Mechanical 0° ~ 360°, Continuous
Compliance
RoHS Status ROHS3 Compliant
