AMS22B5A1BHASL333N
RoHS
RoHS compliant
RoHS compliantPackage Module, Slotted Shaft
Category Sensors, Transducers / Position Sensors - Angle, Linear Position Measuring
Description
ROTARY NON-CONTACT ANALOG SENSOR
PDF
/
Inventory: 9169
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Panel
Mounting Type Panel Mount
Package / Case Module, Slotted Shaft
Technical
Operating Temperature -40°C~125°C
Packaging Bulk
Published 2016
Series AMS22B
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Technology Hall Effect
Voltage - Supply 5V
Base Part Number AMS22B
Output Analog Voltage
Termination Style Solder Lug
Actuator Type Slotted Shaft
Linearity ±0.5%
Sensing Method Hall Effect
For Measuring Rotary Position
Output Signal Clockwise Increase
Rotation Angle - Electrical, Mechanical 10° ~ 330°, Continuous
Compliance
RoHS Status ROHS3 Compliant
