3046L-2-502
RoHS
RoHS compliant
RoHS compliantPackage Module, Wire Leads, Threaded
Category Sensors, Transducers / Position Sensors - Angle, Linear Position Measuring
Description
Res POT 5K Ohm 20% 1/8W 1.59mm (40.41 X 5.69 X 6.58mm) Lead Wire
PDF
/
Buying Options
Total Price: USD $12.36
Unit Price: USD $12.364
≥1 USD $12.364
≥10 USD $11.37664
≥100 USD $9.3984
≥500 USD $8.708656
Inventory: 128
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 40.41mm
Technical
Linear Range 0 ~ 6.35mm (0 ~ 0.25)
For Measuring Linear Position
Resistance Tolerance ±20%
Linearity ±5%
Taper Linear
Size Code 7726
Actuator Type Round Shaft
Rated Power Dissipation (P) 0.125W
Termination Style Wire Leads
Military Standard Not
Base Part Number 3046L
Construction Sealed
Depth 5.69mm
Technology Resistive
Power Rating 125mW
HTS Code 8533.40.80.70
Composition Potentiometer
Resistance 5kOhm
Temperature Coefficient 1000 ppm/°C
ECCN Code EAR99
Termination Lead Wire
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance 20%
Published 2004
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Package / Case Module, Wire Leads, Threaded
Mounting Type Chassis Mount
Mount Chassis Mount
Contact Plating Silver
Supply Chain
Factory Lead Time 11 Weeks
