AS5048B-HTSP
RoHS
RoHS compliant
RoHS compliantPackage 14-TSSOP (0.173, 4.40mm Width)
Category Sensors, Transducers / Position Sensors - Angle, Linear Position Measuring
Description
IC ENCODER ROTARY 14-TSSOP
PDF
/
Buying Options
Total Price: USD $7.63
Unit Price: USD $7.6296
≥1 USD $7.6296
≥10 USD $6.8948
≥100 USD $6.573952
≥500 USD $5.70812
≥1000 USD $5.45153
≥3000 USD $4.970522
Inventory: 1105
Minimum: 1
-
+
Technical Details
Technical
Packaging Tape & Reel (TR)
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Termination SMD/SMT
Terminal Finish Matte Tin (Sn)
Technology Hall Effect
Voltage - Supply 3V~3.6V 4.5V~5.5V
Output I2C, PWM
Termination Style Gull Wing
Body Length or Diameter 5mm
Body Breadth 4.4 mm
Actuator Type External Magnet, Not Included
Output Type PWM
Sensing Method Hall Effect
For Measuring Angle
Rotation Angle - Electrical, Mechanical 0° ~ 360°, Continuous
Operating Temperature -40°C~150°C
Dimensions
Body Height 1.2mm
Compliance
RoHS Status RoHS Compliant
Physical
Number of Pins 14
Surface Mount YES
Package / Case 14-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 24 Weeks
