AS5047U-HTST
RoHS
/
Package 14-TSSOP (0.173, 4.40mm Width)
Category Sensors, Transducers / Position Sensors - Angle, Linear Position Measuring
Description
Tape & Reel (TR) Automotive AEC-Q100 Gull Wing PWM SPI Hall Effect Sensor 4.4mm 3V~3.6V 4.5V~5.5V -40C~150C 0°-360° Continuous
PDF
/
Buying Options
Total Price: USD $7.08
Unit Price: USD $7.081783
≥1 USD $7.081783
≥200 USD $2.741335
≥500 USD $2.644181
≥1000 USD $2.596916
Inventory: 1194
Minimum: 1
-
+
Technical Details
Dimensions
Body Height 1.2mm
Technical
Rotation Angle - Electrical, Mechanical 0° ~ 360°, Continuous
For Measuring Rotary Position
Housing PLASTIC
Actuator Type External Magnet, Not Included
Body Breadth 4.4 mm
Body Length or Diameter 5mm
Termination Style Gull Wing
Output PWM, SPI
Voltage - Supply 3V~3.6V 4.5V~5.5V
Technology Hall Effect
Additional Feature SEATED HGT_MAX,DEVICE ALSO OPERATES AT 5V NOMINAL SUPPLY
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Series Automotive, AEC-Q100
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C
Physical
Surface Mount YES
Package / Case 14-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 22 Weeks
