A1330LLETR-T
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP (0.173, 4.40mm Width)
Category Sensors, Transducers / Position Sensors - Angle, Linear Position Measuring
Description
Angular Type Position Sensor 1200G 4.5V to 5.5V 8-Pin TSSOP T/R
PDF
/
Buying Options
Total Price: USD $2.85
Unit Price: USD $2.8512
≥1 USD $2.8512
≥10 USD $2.32232
≥100 USD $1.884256
≥500 USD $1.752784
≥1000 USD $1.665048
≥3000 USD $1.402174
Inventory: 10815
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Surface Mount
Package / Case 8-TSSOP (0.173, 4.40mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~150°C TA
Packaging Tape & Reel (TR)
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Additional Feature AEC-Q100
Technology Hall Effect
Voltage - Supply 4.5V~5.5V
Output Analog Voltage
Termination Style Gull Wing
Body Length or Diameter 4.4mm
Body Breadth 3 mm
Actuator Type External Magnet, Not Included
Response Time 120 μs
For Measuring Angle
Output Signal Clockwise Increase
Rotation Angle - Electrical, Mechanical 0° ~ 360°
Measurement Range-Max 360 deg
Dimensions
Body Height 1.1mm
Compliance
RoHS Status ROHS3 Compliant
