AK7401 image
Favorite
AK7401 image
Favorite
RoHS
RoHS RoHS compliant
Package 8-SOIC (0.154, 3.90mm Width)
Category Sensors, Transducers / Position Sensors - Angle, Linear Position Measuring
Description SENSOR ROTATION ANGLE 360DEG
PDF
/
Inventory: 5120
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Technical

Rotation Angle - Electrical, Mechanical 0° ~ 360°
Output Signal Programmable
For Measuring Rotary Position
Sensing Method Hall Effect
Linearity ±0.95°
Actuator Type External Magnet, Not Included
Termination Style Gull Wing
Output SPI
Voltage - Supply 4V~5.5V
Technology Hall Effect
Min Operating Temperature -40°C
Max Operating Temperature 150°C
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Series Automotive, AEC-Q100
Published 2015
Packaging Cut Tape (CT)
Operating Temperature -40°C~150°C

Physical

Supplier Device Package 8-SOP
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 12 Weeks
