TPS65290LMRHFR
RoHS
RoHS compliant
RoHS compliantPackage 24-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Special Purpose
Description
Power Management Specialized - PMIC Ultra-Low Pwr Mgmt Unit
PDF
/
Inventory: 2785
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 24-VFQFN Exposed Pad
Number of Pins 24
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 24
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Applications Converter, Energy Harvesting
Subcategory Power Management Circuits
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.6V
Terminal Pitch 0.5mm
Base Part Number TPS65290
Number of Outputs 3
Output Voltage 4V
Number of Channels 1
Max Supply Voltage 5V
Min Supply Voltage 2.2V
Analog IC - Other Type ANALOG CIRCUIT
Voltage - Input 2.2V~5V
Output Current 300mA
Quiescent Current 100nA
Max Duty Cycle 30 %
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
