L6701TR
RoHS
RoHS compliant
RoHS compliantPackage 36-BFSOP (0.295, 7.50mm Width) Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Special Purpose
Description
IC CTRLR 3PH VR10/9/K8 PWRSSO-36
PDF
/
Buying Options
Total Price: USD $1.48
Unit Price: USD $1.47535
≥1 USD $1.47535
≥10 USD $1.21125
≥100 USD $1.17325
≥500 USD $1.13525
≥1000 USD $1.09725
Inventory: 1119
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.5mm
Height Seated (Max) 2.47mm
Technical
Switching Frequency 110kHz
Switcher Configuration PHASE-SHIFT
Control Technique PULSE WIDTH MODULATION
Control Mode CURRENT-MODE
Voltage - Output 0.8V~1.85V
Output Current 1.5A
Voltage - Input 12V
Analog IC - Other Type SWITCHING REGULATOR
Input Voltage-Nom 12V
Qualification Status Not Qualified
Number of Outputs 3
Pin Count 36
Base Part Number L6701
Terminal Pitch 0.5mm
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Applications Controller, Intel VR9, VR10, K8
ECCN Code EAR99
Number of Terminations 36
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C
Physical
Package / Case 36-BFSOP (0.295, 7.50mm Width) Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
