L5954
RoHS
RoHS compliant
RoHS compliantPackage Multiwatt-15 (Vertical, Bent and Staggered Leads)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Special Purpose
Description
IC REG CONV CAR 5OUT MULTIWATT15
PDF
/
Inventory: 5735
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount, Through Hole
Mounting Type Surface Mount
Package / Case Multiwatt-15 (Vertical, Bent and Staggered Leads)
Number of Pins 15
Technical
Operating Temperature -40°C~85°C
Packaging Tube
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin (Sn)
Applications Converter, Car Audio System
Number of Functions 1
Base Part Number L5954
Number of Outputs 5
Voltage - Output 10V 8.5V 5V 8V 5V
Output Voltage 1 10V
Input Voltage (Min) 11V
Input Voltage (Max) 26V
Regulator Type FIXED POSITIVE MULTIPLE OUTPUT LDO REGULATOR
Dropout Voltage1-Max 0.9V
Output Voltage 2 8.5V
Dropout Voltage2-Max 0.9V
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
