UCC3882DW
RoHS
/
Package 28-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Special Purpose
Description
SWITCHING CONTROLLER
PDF
/
Buying Options
Total Price: USD $1.25
Unit Price: USD $1.2496
≥1 USD $1.2496
Inventory: 4502
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 28-SOIC (0.295, 7.50mm Width)
Surface Mount YES
Technical
Operating Temperature 0°C~70°C
Packaging Tube
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 28
Terminal Finish TIN LEAD
Applications Controller, Intel VID code
Technology BICMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 220
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 28
JESD-30 Code R-PDSO-G28
Number of Outputs 1
Input Voltage-Nom 12V
Analog IC - Other Type SWITCHING CONTROLLER
Voltage - Input 5V 12V
Voltage - Output 1.8V~2.05V 2.1V~3.5V
Control Mode CURRENT-MODE
Control Technique PULSE WIDTH MODULATION
Switcher Configuration PUSH-PULL
Switching Frequency-Max 700kHz
Compliance
RoHS Status Non-RoHS Compliant
